Flight Heritage on ISS, Launch Vehicles, and Deep-Space Probes
Gore Spaceflight Cables: The Choice When Failure Is Not an Option
Gore's flagship spaceflight cable line has accumulated extensive flight heritage on the International Space Station, multiple launch vehicle families, and deep-space exploration probes. When program managers need cables whose qualification record speaks for itself, Spaceflight Cables are the answer.
Gore's flagship spaceflight cable line, qualified for crewed and uncrewed missions. With flight heritage on ISS, launch vehicles, and deep-space probes, Spaceflight Cables represent the highest level of space cable qualification — combining ultra-low outgassing, gamma and particle radiation resistance, and extreme mechanical durability in a single comprehensive product line.
Why Choose Gore Spaceflight Cables?
Extensive Flight Heritage Reduces Program Risk
Flight heritage is the ultimate validation of a space cable system. Gore Spaceflight Cables have accumulated service hours on the International Space Station, flown on multiple crewed and uncrewed launch vehicles, and operated in the deep-space environments of interplanetary missions. This heritage record allows program managers to close qualification arguments with demonstrated flight data rather than analysis alone — the highest risk reduction available.
Crewed Mission Qualification Standard
Cables for crewed spacecraft must meet additional requirements for flammability, toxicity, and off-gassing that go beyond robotic mission requirements. Gore Spaceflight Cables meet human spaceflight safety standards including NASA-STD-6001 flammability requirements and toxic off-gas limits — making them the first choice when crew safety is part of the design envelope.
Gamma and Particle Radiation Resistance
Deep space and high-radiation orbital environments (particularly the Van Allen belts and Jupiter's magnetosphere) impose radiation doses that destroy conventional polymer insulations within years. Gore's ePTFE insulation provides inherent resistance to both gamma radiation and particle bombardment, maintaining electrical properties that support multi-decade mission lifetimes in the most demanding radiation environments.
Technical Specifications
- Mission Heritage
- ISS, launch vehicles, deep-space probes
- Mission Type
- Crewed and uncrewed
- Insulation
- Ultra-low outgassing ePTFE
- Radiation Resistance
- Gamma and particle radiation hardened
- Operating Temperature
- -180°C to +260°C
- Flammability
- NASA-STD-6001 compliant
- Outgassing
- ECSS-Q-ST-70-02 / ASTM E595 compliant
Applications
- ISS module internal wiring and replacement harnesses
- Crew vehicle (capsule and orbital plane) harness systems
- Launch vehicle payload fairing and upper stage wiring
- Deep-space probe and planetary lander harness systems
- Space telescope and Earth observation instrument wiring
- Lunar gateway and future exploration architecture wiring
Industries Served
Frequently Asked Questions
What specific missions have used Gore Spaceflight Cables?
Gore Spaceflight Cables have flight heritage on the International Space Station and on multiple launch systems. Specific mission lists are available under NDA for program teams with a legitimate need. Contact RSTECH Electronics to initiate a technical discussion with Gore's space applications team.
Are these cables approved for use on NASA and ESA crewed missions?
Gore Spaceflight Cables have been used on NASA programs including ISS. Formal approval on any new crewed program requires program-specific qualification steps, but the existing heritage and material qualification data dramatically reduces the path to approval compared to unqualified alternatives.
How do Spaceflight Cables differ from other Gore space cable series?
Spaceflight Cables represent Gore's highest-level space qualification, with the broadest heritage record and the most comprehensive qualification data package. Other series (ASW, LEW, CSC, etc.) address specific application niches. Spaceflight Cables are the general-purpose premium offering where maximum qualification confidence is required.
Can RSTECH supply Spaceflight Cables to Israeli space programs?
Yes. RSTECH Electronics is the authorized Gore representative in Israel and supports Israeli space programs including satellite manufacturers, launch support operations, and research institutions. We handle the full procurement and documentation chain from Gore's production facilities to Israeli program teams.
Ready to source Spaceflight Cables in Israel?
Contact RSTECH Electronics — your authorized Gore representative in Israel.
