Professional USB Cables Built for Demanding Duty Cycles
USB Cables With the Flex Life and Signal Integrity Professional Applications Demand
Gore USB Cables bring professional-grade signal integrity, exceptional flex life, and slim-profile construction to medical devices, industrial instruments, and portable equipment — applications where consumer USB cables fail within weeks of continuous use.
Slim, flexible USB cables with superior flex life and signal integrity for use in medical devices, industrial equipment, and portable electronics.
Why Choose Gore USB Cables?
Reliability That Outlasts Consumer USB Cables
Consumer USB cables are designed for occasional plugging and unplugging — not for millions of flex cycles on a robotic arm or medical device cart. Gore's USB cables use the same fine-wire, fluoropolymer-insulated construction as Gore's other professional cables, providing flex life measured in years of continuous operation rather than months.
Signal Integrity at High Speeds and Extended Lengths
USB 3.x SuperSpeed+ protocols are highly sensitive to cable impedance and signal quality. Gore's controlled-impedance construction and low-loss dielectric maintain the electrical eye diagram required for reliable 5 Gbps and 10 Gbps operation, including at cable lengths where ordinary cables fail USB compliance testing.
Slim Profile for Space-Constrained Devices
Medical instruments, handheld analyzers, and portable industrial devices have limited port access and tight internal routing channels. Gore's fine-wire USB cables have significantly smaller outer diameters than standard USB cables, making them easier to route cleanly and reducing connector strain in compact enclosures.
Technical Specifications
- USB Standards
- USB 2.0 / USB 3.2 Gen 1 & Gen 2
- Max Data Rate
- 10 Gbps (USB 3.2 Gen 2)
- Operating Temperature
- -55°C to +105°C
- Minimum Bend Radius
- 15 mm
- Shielding
- Overall braid + data pair foil
- Connector Types
- Type-A, Type-B, Micro, Type-C
Applications
- Medical device and diagnostic instrument USB ports
- Robotic and automated equipment USB peripheral connections
- Industrial hand-held scanner and reader cables
- Laboratory instrument data acquisition links
- Portable ultrasound and patient monitoring device connections
- Factory automation barcode reader and HMI cables
Industries Served
Frequently Asked Questions
Are Gore USB cables compliant with USB-IF specifications?
Gore USB cables are designed to meet or exceed USB-IF electrical specifications. For applications requiring formal USB-IF certification, contact RSTECH Electronics to identify the appropriate qualified cable assembly.
Do Gore USB cables support USB Power Delivery (USB PD)?
Gore USB cables are available in configurations that support USB Power Delivery for Type-C implementations. The appropriate cable rating depends on the power level required. Contact RSTECH to specify the correct cable for your PD application.
How long can Gore USB cables be while maintaining USB 3.x speeds?
Maximum length for reliable USB 3.x operation depends on the specific cable construction. Gore's controlled-impedance, low-loss construction extends achievable lengths beyond consumer cable limits. Contact RSTECH with your required length and speed for cable specification guidance.
Are these cables suitable for sterilization environments in medical applications?
Gore USB cables use fluoropolymer materials that are chemically resistant to common sterilization agents including alcohol, hydrogen peroxide, and many disinfectant solutions. For autoclave or gamma sterilization compatibility, contact RSTECH for specific guidance on the appropriate construction.
Ready to source USB Cables in Israel?
Contact RSTECH Electronics — your local authorized Gore representative — for pricing, availability, and technical support.
