4K Video Over Distance — Without Compromise
Ultra-Thin HDMI Cables That Deliver 4K Where Standard Cables Fail
Gore HDMI Cables maintain full 4K/UHD signal integrity at run lengths and in dynamic routing scenarios where standard HDMI cables produce signal dropouts, artifacts, and HDCP handshake failures. Engineered for professional, medical, and industrial display applications.
Ultra-thin, flexible HDMI cables that deliver uncompromised 4K video over distances where standard cables suffer signal degradation.
Why Choose Gore HDMI Cables?
4K Signal Integrity at Extended Lengths
Consumer HDMI cables degrade 4K/60Hz signals beyond 5–7 meters due to increasing capacitance and loss. Gore's low-loss dielectric and controlled differential pair geometry maintain eye-diagram compliance at significantly longer runs, eliminating expensive active HDMI extenders in most professional installations.
Flex Life for Articulating Displays and Camera Arms
Surgical booms, robotic camera mounts, and articulating monitor arms flex their HDMI connections thousands of times per year. Standard HDMI cables fail within months in these applications. Gore's rated flex-life construction keeps video streams running through years of dynamic use.
Slim Profile for Challenging Routing
Gore's ultra-thin HDMI cable diameter — often less than half that of consumer HDMI — makes it practical to route video through cable conduits, behind displays, and through wall penetrations that standard cable cannot navigate. This simplifies installation and improves aesthetics in professional installations.
Technical Specifications
- HDMI Version
- HDMI 2.0 (4K/60Hz, HDR)
- Max Bandwidth
- 18 Gbps
- Max Resolution
- 4K UHD (3840×2160) @ 60Hz
- Cable OD
- ~4.0 mm (ultra-thin)
- Operating Temperature
- -40°C to +85°C
- Shielding
- Individual pair foil + overall braid
Applications
- Surgical suite display boom and monitor arm connections
- Medical imaging system display output cabling
- Industrial HMI panel and operator station video links
- Broadcast camera and production monitor cabling
- Simulation and training system display networks
- Conference room and control room display installations
Industries Served
Frequently Asked Questions
Do Gore HDMI cables support HDCP 2.2 for 4K content protection?
Yes. Gore HDMI cables faithfully pass all HDMI data signals including the HDCP 2.2 authentication traffic required for 4K protected content. The controlled impedance construction ensures the handshake completes reliably even at extended lengths.
What is the maximum length available for 4K/60Hz operation?
Maximum length for 4K/60Hz operation depends on the specific Gore cable construction. Achievable lengths typically exceed standard cable specifications. Contact RSTECH Electronics with your required length and resolution and we will recommend the appropriate product.
Are these cables suitable for use in medical environments?
Yes. Gore HDMI cables are specified in surgical suite display installations and medical imaging workstation connections. Their reliable signal performance reduces the risk of display dropouts during critical procedures.
Can these cables handle audio return channel (ARC) and CEC signals?
Yes. Gore HDMI cables support all HDMI feature signals including ARC, eARC, CEC, and HPD in addition to the video and audio data channels.
Ready to source HDMI Cables in Israel?
Contact RSTECH Electronics — your local authorized Gore representative — for pricing, availability, and technical support.
