IEEE 1394 Performance Built for Industrial Duty Cycles
FireWire Cables With the Flex Life That Demanding Imaging Systems Require
Gore FireWire (IEEE 1394) Cables deliver consistent isochronous data transfer and signal integrity through millions of flex cycles — critical for machine vision systems, industrial cameras, and data acquisition equipment that move continuously in operation.
High-speed FireWire (IEEE 1394) cables offering exceptional flex performance and signal integrity for industrial imaging and data acquisition systems.
Why Choose Gore FireWire Cables?
Continuous-Flex Performance Without Frame Drops
Machine vision cameras mounted on robotic arms, gantry systems, and conveyor-tracking platforms must maintain uninterrupted image streams through constant motion. Gore FireWire cables are engineered for continuous-flex environments, maintaining full electrical performance through millions of bend cycles without signal dropouts.
Isochronous Transfer Integrity for Real-Time Data
FireWire's isochronous transfer mode guarantees bandwidth reservation for time-sensitive data streams — but only if the cable maintains electrical integrity. Gore cables preserve the tight differential pair skew and impedance matching that isochronous FireWire transfer requires, preventing the timing errors that corrupt image data.
Weight Savings That Improve Machine Performance
In robotic camera mounts and scanning systems, cable weight affects acceleration, repeatability, and motor sizing. Gore's fine-wire FireWire cables weigh significantly less than standard versions, improving dynamic performance and reducing mechanical stress on mounting hardware.
Technical Specifications
- Standard
- IEEE 1394a / 1394b
- Data Rate
- 400 Mbps / 800 Mbps
- Operating Temperature
- -55°C to +105°C
- Minimum Bend Radius
- 20 mm
- Shielding
- Individual pair foil + overall braid
- Connector Options
- 4-pin, 6-pin, 9-pin
Applications
- Industrial machine vision camera links on robotic arms
- Conveyor-mounted inspection system image transfer
- Medical endoscope and surgical camera data connections
- Scientific instrument high-speed data acquisition
- Motion-capture studio camera link cabling
- Semiconductor wafer inspection system imaging buses
Industries Served
Frequently Asked Questions
What data rates do Gore FireWire cables support?
Gore FireWire cables support IEEE 1394a at 400 Mbps and IEEE 1394b (FireWire 800) at 800 Mbps. The appropriate standard depends on your camera or device interface.
Are these cables rated for cable carrier (energy chain) applications?
Yes. Gore FireWire cables are specifically engineered for continuous-flex applications including cable carriers, festoon systems, and robotic arm installations where the cable is in constant motion.
Can I get custom lengths for integration into existing equipment?
Custom lengths are available through RSTECH Electronics. Provide your required length and connector specifications and we will source the appropriate Gore cable assembly.
Is FireWire still relevant for new industrial designs?
Yes — FireWire remains widely used in industrial machine vision, scientific imaging, and certain medical device applications where its isochronous transfer capabilities and device power delivery (6-pin) are valuable. Gore continues to support these applications with current cable solutions.
Ready to source FireWire Cables in Israel?
Contact RSTECH Electronics — your local authorized Gore representative — for pricing, availability, and technical support.
